7
DETECTION SYSTEM: Optical defect sensing system, using CCD
line array and associated electronics.
Detects longitudinal and transverse creases,
wrinkles, and other physical defects.
• Three-channel system identifies the area of
tape containing damage.
• location and number of defects are reported
on the display and by the optional printer.
OPERATOR CONTROLS: Three Switch clusters contain switches for
the tape transport system, display and data
entry systems, and the option printer
system.
ELECTRONICS:
• Microprocessor based control system with
ROM and battery backup RAM memory
devices. Digital electronics control all
motors, the transport system, defect
detection, keyboard, and displays. The
memory stores defect data and information.
DIAGNOSTICS SYSTEM:-The status of
all sensors and mechanisms in the Pro Line
machine is monitored and displayed on
special diagnostic displays seen on the LCD
module.
PRINTER OPTION: This
optional electronics package and 20
column printer produces a printed report of
the tape inspection on special thermal
printing paper. (To prevent printhead
damage only use paper specified by RTI.)
ERASE OPTIONS: There are two erase options available for
the Pro Line machines. One designed for
oxide videotape and the other designed for
oxide and metal Betacam videotape. The
full width of the videotape is erased when
this function is selected by the operator.
Cassettes with erase protection tabs
activated will not be erased by the 4100.
The display will indicate "Erase Protected".
POWER: 117 VAC,3 Amp., 60 Hz. Standard
• 220, 240 VAC; 50Hz. Special Order
DIMENSIONS AND WEIGHT
• W x 13" H x 20" D.
• pounds.
