RTRMAX RTM852 User Manual

Проверил: Р.Ч./24.03.2015г
PRODUCT UNITS
1. Reset Switch
2. The indicator of dry working
3. Voltage indication
4. Motor Connections
5. Pressure adjustment
6. 1 inch
7. Electric Connection
8. 1 inch
9. The Gauge
TECHNICAL SPECIFICATIONS
RTM852
 Input Voltage 220-250 V
 Max. Current 12A
 The pressure rank 1.5-2.2 bar
 Frequencey 50 – 60 Hz
 Densitiy Max 10 A
 Protection Grade IP65
 Max. Working Pressure 10bar
 Max. Temperature 60 C
 The Gauge 40mm 0:120 bar

RTRMAX RTM852 Specifications

General

Brand	RTRMAX
Model	RTM852
Category	Controller
Language	English
