EN-4
8. Silk dome tweeter
9. Neodymium woofer
10. Remote sensor
11. Optical input (Toslink)
12. Wall mounting (1/4-20 UNC thread)
2 Overview
8
15
16
10
14
13
12
11
9
Right speaker (front) Right speaker (back)
13. DC power socket
14. Aux input (3.5mm stereo jack)
15. Sub-woofer output (phono)
16. Output to left speaker (3.5mm mono jack)
OPTICAL OUT TO
LEFT
AUX IN SUB OUT14V 2.0A
