6. TO REMOVE THE STOCK: (Be certain the bolt has been removed from the
rifle.)
a. Remove ramrod from stock. Unscrew barrel band screw and remove
barrel band forward off the stock and barrel. (See Fig. 23)
b. Unscrew and remove the two screws in the trigger guard
counterclockwise and carefully remove trigger guard. (See Fig. 24) Note
that the longer screw goes in the rear hole of the trigger guard.
c. VERY CAREFULLY lift the barrel/receiver assembly from the stock. (See
Fig. 25)
