Rugged Computing Y041 - Assembly Step 1; Step 1 A: Attach Front Leg to Front Stabilizer; Step 1 B: Attach Front Leg to Main Frame; Step 1 C: Attach Rear Leg to Main Frame

10
STEP
1
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware rst in this step. Wrench tighten ALL hardware at the end of
STEP 1C. Some components may be pre-assembled. Nylon lock nuts will not fully screw
onto bolts, they must be wrench tightened to fully go on.
1A. AttachFrontLeg(B)toFrontStabilizer(A)using:
(#1) M12x100mm Hex Head Bolt, QTY 2
(#6) M12 Flat Washer, QTY 4
(#9) M12 Nylon Lock Nut, QTY 2
1B. AttachFrontLeg(B)toMainFrame(D) using:
 (#2) M12x25mm Hex Head Bolt, QTY 2
(#6) M12 Flat Washer, QTY 2
1C. AttachRearLeg(C)toMainFrame(D) using:
 (#2) M12x25mm Hex Head Bolt, QTY 2
(#6) M12 Flat Washer, QTY 2

