Rugged Computing Y041 - Assembly Step 2; Step 2 A: Attach Handle to Rear Leg; Step 2 B: Attach Pad to Main Frame

12
STEP
2
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware rst in this step. Wrench tighten ALL hardware at the end of
STEP 2B. Some components may be pre-assembled. Nylon lock nuts will not fully screw
onto bolts, they must be wrench tightened to fully go on.
2A. AttachHandle(E)toRearLeg(C)using:
 (#3) M10x70mm Hex Head Bolt, QTY 2
(#7) M10 Flat Washer, QTY 2
2B. AttachPad(#12)toMainFrame(D)using:
(#5) M8x25mm Hex Head Bolt, QTY 8
(#8) M8 Flat Washer, QTY 8
