19
US I american
PRECISION TOOLS
Drilling unit RS126e
Drilling mechanism RS126e
Pos. Description Article no. Quantity
1 Machined body + brass plate 711 2 200 1
2 Spring plunger 711 4 007 1
3 Pinion shaft 711 3 217 1
4 Star grip with threaded rod 711 4 003 1
5 Bearing bowl 711 3 212 2
6 Safety ring 611 9 306 2
7 Balance plate 611 9 813 1
8 Threaded pin M5x12 611 9 004 4
9 Cylinder head screw M5 x 10 611 9 024 1
10 Toothed disc 5.3 mm 611 9 405 3
11 Hexagon socket screw M3x8 611 9 045 10
12 Cable gland 611 9 854 1
13 Cool bottle 711 4 013 1
14 Lid for cool bottle 108 1 01-4 1
15 Connection cooling 711 4 010 1
16 Switch magnet 611 4 402 1
17 Adapter for handle 711 3 216 1
18 Hand lever compl. 711 4 016 3
19 Set screw with flat point M8x8 611 9 043 3
20 Guide rail 611 3 228 2
21 Cylinder head screw M5x20 611 9 002 6
22 Cylinder head screw M3x20 711 4 001 2
23 Cylinder head screw M8x30 611 9 034 1
24 Cylinder head screw M8x20 611 9 063 1
25 Magnet + fine adjustment compl. 711 1 001 1
26 Carriage 711 3 218 1
27 Toothed rack 611 3 222 1
28 Cylinder head screw M6x12 611 9 026 3
29 Cylinder head screw M8x16 611 9 020 6
Pos. Description Article no. Quantity
30 Motor cap 711 2 005 1
31 Screw 3.9x50 611 3 504 4
32 Tapping screw HC 2.9x13 711 2 504 2
33 PCB - 115 V 611 2 556 1
34 Strain relief bushing 711 2 014 1
35 Carbon brush, cpl. 6.3x10x18 L85F13 711 2 503 2
36 Cold-forming tapping screw ZM4x12 611 1 530 4
37 Corrugated spring washer B4 611 1 533 4
B2 Pocket brush holder, cpl. 611 1 528 2
38 Motor housing 711 2 004 1
39 Pole ring, cpl. 711 2 501 1
40 Tapping screw C 3.9x60 611 1 531 2
41 Grooved dowel pin 4x12 611 3 215 1
42 Gearbox seal 611 1 501 1
43 Gear bearing plate 711 2 007 1
44 Air guide ring 711 2 009 1
45 Circlip 11/1 611 2 519 1
46 Grooved ball bearing 6001 2RS 711 2 017 1
47 Circlip 28/1.2 611 1 524 1
B1 Armature, cpl. - 115 V 711 2 506 1
48 Grooved ball bearing 608 2Z 611 1 526 1
49 Press board disc 611 1 550 1
50 Magnetic disc 611 1 551 1
51 O-ring 22x2.5 611 1 527 1
52 Carbon support strand 711 2 505 2
53 Disc 711 2 001 1
54 Shaft sealing ring 25x40x7 711 2 002 2
