1.2 Trace5 Technical Information
Indication LED Patterns
Mode
Pattern
Description
GNSS fix
acquired
Once every second
Good cellular signal, no network
connection
Once every 4 seconds
Good cellular signal, connected to network
Always on, blinks once every 4 seconds
Link with the server is open
Once every 0.2 seconds
No signal
GNSS fix not
acquired
Twice every second
Good cellular signal, no network
connection
Twice every 4 seconds
Good cellular signal, connected to network
Always on, blinks twice every 4 seconds
Link with the server is open
Twice every 0.2 seconds
No signal
Sleep mode
Once every 10 seconds
The device is in sleep mode

Device Pinout
Pin
Pin no.
Wire color
Description
+BAT
7
Red
Power supply 8-30 V DC
GND
1
Black
Ground connection
DIN1
2
Pink
Digital input 1
DIN2*
6
Blue
Digital input 2
DIN3*
11
White
Digital input 3
DIN4*
5
Yellow
Digital input 4
AIN1
3
Grey
Analog input 1
AIN2*
4
Green
Analog input 2
DOUT1
8
Purple
Digital output 1
DOUT2
9
Orange
Digital output 2
1W Pwr*
12
White/Red
1-Wire Power
1WData*
10
Green/Yellow
1-Wire Data
* – Not available with pre-revision Trace5-LTM devices.
Physical Characteristics
