RUPTOR R3 - Page 18

18
Whole-vehicle
The Project Content Parameters R3 Parameters R6
Vehicle parameters Expand: Long, width
and height
1247X675X1170 1247X675X1170
Folfolding: length,
width and height
1247X675X556 1247X675X556
Net weight 28 kg 29 kg
Top speed 20-45 km/h 20-55 km/h
Range age Up to 55 km Up to 55 km
Climbing ability 30 degrees 30 degrees
Operating temperature -10~40 degrees -10~40 degrees
Storage temperature -20~40 degrees -20~40 degrees
Waterproof rating IP54 IP54
Charging time 8 ~ for 10 hours 8 ~ for 10 hours
Battery parameters Rated voltage 48V 48V
Rated capacity 17.5 Ah 17.5 Ah
Motor parameters Motor dimensions In the 10 inches In the 10 inches
Maximum torque 32Nm 55Nm
Rated voltage 48V 48V
Rated power 800W 2 x 1000W
Maximum power 1000W 2 x 1100W
Motor control mode The DC flow
is brushless
The DC flow
is brushless
Brake Brake braking mode Front and rear
mechanical disc brake
+ power off
Front and rear
mechanical disc brake
+ power off
Outer tire Outer tire form 10 inch 10 inch
Outer tire pattern road pattern road pattern
Charger Output power 84W 84W
Input the voltage 100V~240V 100V~240V
Output voltage 54.6V 54.6V
Output current 2A 2A
Maximum load 150 kg 150 kg
