3. Transport wheel assembly
Mount the wheels so that the tire profile is oriented according to the figure below.
Rotary cutter guard.
Insert bushing A onto shaft B.
Fit the rear guard to the B axle then insert the locking pin into the B axle hole.
Assemble the tiller
Unscrew the two M12 nuts, remove the PTO cover and connect the cutter assembly to the machine then
tighten the nuts.
