32 RUSH MH 5 Profile User Manual
Chan. Value Function
233-255 counter clockwise, slow→fast
7
Gobo wheel 1 indexing/rotation
Wheel indexing
0-255 Indexed position, 0°→180°
Wheel rotation
0-2 No rotation
3-126 Clockwise rotation, fast→slow
127-129 Stop
130-253 Counter-clockwise rotation, slow→fast
254-255 Stop
8
Gobo wheel 2 (static gobos)
Continuous scrolling
0 Open
1-14 Open → Gobo1
15 Gobo 1
16-29 Gobo 1 → Gobo 2
30 Gobo 2
31-44 Gobo 2 → Gobo 3
45 Gobo 3
46-59 Gobo 3 → Gobo 4
60 Gobo 4
61-74 Gobo 4 → Gobo 5
75 Gobo 5
76-89 Gobo 5 → Gobo 6
90 Gobo 6
91-104 Gobo 6 → Gobo 7
105 Gobo 7
106-119 Gobo 7 → Open
120-160 Open
Stepped scrolling
161-163 Gobo 1
164-166 Gobo 2
167-169 Gobo 3
170-172 Gobo 4
173-175 Gobo 5
176-178 Gobo 6
179-181 Gobo 7
182-192 Open
Continuous wheel rotation
193-214 Clockwise, fast→slow
