5
MAINTENANCE
Changing or cleaning the dust bag: when the indicator turns to be red, it is time to clear
the dust or replace with a new bag. (Fig1) To do this:
• Open the front cover by clicking down the clip. (Fig2)
• Take out the bag then remove the full dust bag. (Fig3)
Changing the motor filter:
• Press and click down the clip to remove the outlet cover to change the filter. (Fig4,5)
• The motor protection filter should be cleaned or changed when it´s dirty. (Fig6,7)
Fig. 1
Fig. 5 Fig. 6 Fig. 7
Fig. 2 Fig. 3
Fig. 4
TECHNICAL DATA
Voltage 220–240V~50/60Hz
Output 850W
Protection class
Bag capacity 2,5 l
Filtering HEPA-filter
Cord length 5 m
Total range 7,5 m
Metal telescopic tube 48–78 cm
Sound level max 79 dB
Dimensions 450 x 310 x 280 mm
Weight 4 kg
