5
MAINTENANCE
• Change the dust bag: when the wind indicator turns to be red, it is time to clear
the dust or replace with a new bag. (Fig1)
1. Open the front cover by clicking down the clip. (Fig2)
2. Take out the bag then remove the full dust bag. (Fig3)
• Exchange the outlet filter: Press and click down the clip to remove the outlet
cover to change the filter. (Fig4,5)
• The motor protection filter should be cleaned or changed when it´s dirty. (Fig6,7)
Fig. 1
Fig. 5 Fig. 6 Fig. 7
Fig. 2 Fig. 3
Fig. 4
TECHNICAL DATA
Voltage 220–240V~50/60Hz
Output 800W
Protection class
Bag capacity 3,5 l
Filtering HEPA-filter
Cord length 7 m
Total range 9,5 m
Metal telescopic tube 58–90 cm
Sound level max 69 dB
Dimensions 500 x 3 30 x 325 mm
Weight 5,9 kg
