MANUAL 2010 March
17
TRANSPORTING YOUR WORK PLATFORM
MODEL 195 MODEL 139
TRAIL POSITION IN TRAIL POSITION
Shown above is an example of a Model 195 Shown above is an example of a Model 139.
in trial position for highway tow. The example in trail position for highway tow. The example
consists of a Model 195 with optional wide tires, consists of a Model 139 with optional wide tires,
2” ball hitch, and 2 Intermediate Levels. Saddle 2” ball hitch, 1 Intermediate Level, and a Light Bar.
weights are not to be lift on unit when towing To tow, in trail position, adjusting arm threads
and should not be transported separately. Must be screwed completely in to give a clearance
of approximately 13ft. 5in.
When readying for tow behind a vehicle, be sure REAR STEERING TONGUE IS LOCKED DOWN IN PLACE
ADDITIONAL WINCH OPERATING INSTRUCTIONS
WHEN LOWERING THE PLATFORM(S) ONLY 1 PERSON SHOULD BE OPERATING THE WINCH AND
RELEASE ROPE FOR EACH WINCH. THE OPERATOR SHOULD NOT
BE UNDER THE PLATFORM.
THE OPERATOR SHOULD FIRMLY GRAB THE WINCH IN ONE HAND AND THE ROPE IN THE OTHER.
IF YOU LOSE YOUR GRIP ON THE WINCH, RELASE THE ROP.
DO NOT ALLOW ANYONE EXCEPT THE WINCH OPERATOR TO HOLD THE ROPE.
