RYOBI 7-1/4 in. CIRCULAR SAW – MODEL NUMBER CSB124
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
CIRCULAR SAW or when ordering parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 660208052 Screw (M4 x 16 mm, Pan Hd.) ...................... 7
2 524937001 End Cover ..................................................... 1
3 562998001 Rubber Bumper ............................................ 2
4 290075001 Brush Assembly ............................................ 2
5 660259008 Screw (M4.5 x 35 mm) .................................. 3
6 524935001 Motor Housing .............................................. 1
7 681304001 Ball Bearing (608-2RS) ................................. 1
8 230451001 Motor Assembly (Inc. Key No. 7) .................. 1
9 661748001 Screw (4.2 x 1.4 x 44, Type B Pan Hd.) ........ 2
10 941120012 Warning Label ............................................... 1
11 525084001 Volute ............................................................ 1
12 634292001 Spindle Lock ................................................. 1
13 693411002 Compression Spring ..................................... 1
14 670974003 Lock Nut (M5) ............................................... 1
15 202001005 Upper Blade Guard Assembly
(Inc. Key No. 10, 18, and 48) ........................ 1
16 561984001 Bumper ......................................................... 1
17 660193005 Shoulder Screw (M5 x 20 mm) ..................... 1
18 680413005 Bushing ......................................................... 1
19 305403001 Output Shaft and Gear Assembly ................. 1
20 680980003 Roll Pin .......................................................... 1
21 305401001 Lower Blade Guard Support Assembly
(Inc. Key No. 19) ........................................... 1
22 661349001 Screw (M4 x 16 mm, Pan Hd.) ...................... 4
23 680672006 Torsion Spring ............................................... 1
24 524934001 Lower Blade Guard ....................................... 1
25 693438001 Retaining Ring .............................................. 1
26 611791001 Inner Blade Washer ....................................... 1
27 680775001 Outer Blade Washer ...................................... 1
28 660988001 Blade Screw (5/16-18 x 9/16 in.) .................. 1
29 202143001 Handle Assembly .......................................... 1
30 760476003 Switch ........................................................... 1
31 790009001 Closed End Wire Connector ......................... 1
32 551060002 Bend Relief ................................................... 1
33 730372029 Power Cord ................................................... 1
34 305407001 Base Assembly (Inc. Key Nos. 38-43) .......... 1
35 612031001 Depth Lock Nut (1/4-20) ............................... 1
36 634295001 E-Ring ........................................................... 1
37 634293001 Depth Lock Lever ......................................... 1
38 660104010 Carriage Bolt (1/4-20 x 5/8 in.) ..................... 1
39 660106007 Hex Nut (8-32) ............................................... 1
40 660112006 Screw (8-32 x 11/32 in., Pan Hd.) ................. 1
41 301124010 Bevel Lock Knob ........................................... 1
42 680771002 Washer (OD5/8 x ID7/16 x 1/16t) .................. 1
43 634389001 Blade Wrench ............................................... 1
44 941121019 Data Label ..................................................... 1
45 941120008 Warning Label ............................................... 1
46 940304501 Logo Label .................................................... 1
47 693616001 Carriage Bolt (1/4-20 x 5/8 in., Special) ........ 1
48 681717001 Ball Bearing (6000-2RS) ............................... 1
49 680776001 Spring Washer .............................................. 1
50 680856014 Blade (7-1/4 in.) ............................................ 1
Not Shown:
202218001 Edge Guide Kit (Optional) ............................. 1
200673002 Dust Nozzle Kit (Optional) ............................. 1
990000075 Operator’s Manual
1-29-13
(Rev:03)
