RYOBI 7-1/4 in. CIRCULAR SAW – MODEL NUMBER CSB124
WIRING DIAGRAM
RED
RED
MOTOR
WHITE
WHITE
WIRE NUT
BLACK
BRUSH ASSEMBLY
SWITCH
BLACK
POWER CORD
