Ryobi csb140lz - Product Specifications; Features

9
FEATURES
PRODUCT SPECIFICATIONS
n Blade Diameter ................................. 7-1/4 in. (184 mm)
n Blade Arbor.............................................5/8 in. (16 mm)
n Cutting Depth at 0°............................. 2-3/8 in. (60 mm)
n Cutting Depth at 45°....................... 1-13/16 in. (46 mm)
n Cutting Depth at 51.5°........................ 1-5/8 in. (41 mm)
n Input............................ 120 V, 60 Hz, AC Only, 14 Amps
n No Load Speed..............................................5500 /min.
n Net Weight .............................................. 12 lbs. (5.4 kg)
n Laser Guide ......................Class IIIa, 5mW max, 650nm
Fig. 1
SWITCH
UPPER BLADE
GUARD
BASE
LOWER
BLADE
GUARD
BLADE
DEPTH
ADJUSTMENT
KNOB
LOWER BLADE
GUARD HANDLE
BEVEL
ADJUSTMENT
KNOB
MOTOR
HOUSING
HANDLE
EDGE GUIDE
DUST CHUTE
EDGE GUIDE
KNOB
SPINDLE LOCK
BUTTON
LASER GUIDE
LASER GUIDE
LASER GUIDE
SWITCH
