10
LOOSE PART LIST
A: Support arm (6pcs)
B: Rip fence assembly
C: Leg stand (4pcs)
D: Blade guard assembly
E: Left extension table
F: Right extension table
G: Mitre gauge assembly
H: Rear extension table
I: Cross Brace (4pcs)
J: Blister pack with screws
K: Push stick
SPECIFICATION
Input voltage
Watts
Blade diameter
Bore size
No load speed
Depth of cut at 90
O
Depth of cut at 45
O
Main table size
Left/Right Extension table sizes
Sound pressure level
Net weight
230 V ~ 50 Hz
1500W
254mm
30mm
4500min-1
80mm
55mm
638mm x 430mm
638mm x 150mm (x2)
99dB(A)
23.5 kg
WARNING!
Noise can be a health hazard. When the noise level exceeds 85 dB (A) be sure to wear ear
protection.
PROPER USE OF MACHINE
This machine is designed to rip and cross
cut wood exclusively up to maximum
thickness of 80mm. For correct operation
it must be fixed and operated as explained
in this manual.
RESTRICTIONS OF USE
DO NOT cut timber greater than 80mm
DO NOT cut metal, stone, rubber, plastic
bones, etc.
DO NOT cut logs or round timber.
DO NOT use to rebate, mould or trench.
DO NOT fit any other tool or combination of
blades.
DO NOT use as a bench or work test.
DO NOT weld machine.
DO NOT modify the machine or its
guards/controls
DO NOT run the machine before removing
all packaging.
DO NOT use with any covers/guards
removed.
DO NOT use High Speed Steel (HSS)
blades.
DO NOT use the saw for slotting (stopped
groove).
