Ryobi GD200A - Page 14

14 - English
LOOSE PARTS
The following items are included with your garage door opener:
A. Header Bracket ..................................................................................................................................................... 1
B. Wing Nut ............................................................................................................................................................... 2
C. Mounting Strap ..................................................................................................................................................... 2
D. Door Bracket ......................................................................................................................................................... 1
E. Curved Door Arm .................................................................................................................................................. 1
F. Straight Door Arm ................................................................................................................................................. 1
G. Emergency Release Rope .................................................................................................................................... 1
H. Large Clevis Pin .................................................................................................................................................... 1
I. Medium Clevis Pin ................................................................................................................................................ 1
J. Small Clevis Pin .................................................................................................................................................... 1
K. Bracket ................................................................................................................................................................. 2
L. Hitch Pin ............................................................................................................................................................... 3
M. Sleeve ................................................................................................................................................................... 3
N. Outer Trolley .......................................................................................................................................................... 1
O. Entrapment Warning Label (Eng., Fr., and Sp.) .................................................................................................... 3
P. Support Rail .......................................................................................................................................................... 3
Q. End Rail ................................................................................................................................................................. 1
R. Sensor Bracket ..................................................................................................................................................... 1
S. Safety Sensor ....................................................................................................................................................... 2
T. Pulley Rod Assembly ............................................................................................................................................ 1
U. Power Head .......................................................................................................................................................... 1
V. Outdoor Keypad ................................................................................................................................................... 1
W. Car Remote ........................................................................................................................................................... 2
X. Indoor Keypad ...................................................................................................................................................... 1
Y. Sprocket ............................................................................................................................................................... 1
Z. Front Brace ........................................................................................................................................................... 1
aa. Nut (7/16 in.) ....................................................................................................................................................... 10
bb. Bolt (7/16 in. x 3/4 in.) ........................................................................................................................................... 6
cc. Lag Screw (7/16 in. x 1-1/2 in.) ............................................................................................................................. 2
dd. Self-tapping Screw ............................................................................................................................................... 2
ee. Lock Nut (1/2 in.) .................................................................................................................................................. 2
ff. Bolt (1/2 in. x 1 in.) ................................................................................................................................................ 2
gg. Nail (2 in.) .............................................................................................................................................................. 2
hh. Screw (1 in., Phillips Hd.) ...................................................................................................................................... 2
ii. Washers (7/16 in.) ................................................................................................................................................. 6
jj. Drywall Anchor ...................................................................................................................................................... 2
kk. Insulated Staple .................................................................................................................................................. 30
ll. Lag Screw (1/2 in. x 1-1/2 in.) ............................................................................................................................... 2
mm. Screw (1-1/2 in., Phillips Hd.) ............................................................................................................................... 2
nn. Instructions Label (Eng., Fr., and Sp.) ................................................................................................................... 3
