RYOBI JIG SAW – MODEL NUMBER JS550
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock
or electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized
Service Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
JIG SAW or when ordering repair parts.
PARTS LIST
Key Part
No. Number Description Qty.
Key Part
No. Number Description Qty.
1 300187005 SCROLLING ASSEMBLY ..........................................1
2 511772001 SCROLLING COVER.................................................1
3 511770001 SCROLLING..............................................................1
4 671142001 SAW BAR GUIDE BUSHING.....................................1
5 660206014 * SCREW (M3.5 x 14 mm) ...........................................1
6 511773001 SCROLLING RELEASE KNOB .................................1
7 301011001 SCROLLING RELEASE KNOB ASSEMBLY ..............1
8 671146001 * SPRING (13.5 mm X 1.25 mm X 18 mm) ..................1
9 550427001 WASHER ...................................................................1
10 300306015 HEAT SINK ASSEMBLY ............................................1
11 680974001 SLEEVE BEARING ....................................................1
12 640492001 HEAT SINK ................................................................1
13 671147001 GUARD WIRE............................................................1
14 630845001 SLIDE GUIDE PLATE.................................................1
15 631252001 SPRING PLATE .........................................................1
16 301007001 SAW BAR AND BLADE CLAMP ASSEMBLY............1
17 671152001 SAW BAR ..................................................................1
18 671153001 CROSS SLIDE COLLAR............................................1
19 690072002 SPRING PIN .............................................................2
20 631085001 SAW BAR SLIDE BRACKET......................................1
21 671038001 BEARING SLEEVE ....................................................1
22 550427001 WASHER ...................................................................1
23 680839002 NEEDLE ROLLER......................................................1
24 640789001 CLAMP HOUSING ....................................................1
25 511826001 BLADE CLAMP LEVER .............................................1
26 671319001 * E-RING (2.0 mm X 4 mm X 0.4 mm) .........................2
27 690387001 COIL SPRING............................................................1
28 690377003 RIGHT LINKAGE ARM ..............................................1
29 671318001 ROLLER ....................................................................1
30 690377004 LEFT LINKAGE ARM.................................................1
31 690387002 COIL SPRING............................................................1
32 660182006 * SCREW (#6 X 12 mm) ...............................................4
33 660165003 * SCREW (M4 X 18 mm) ..............................................1
34 660208005 * SCREW (M4 X 16 mm) ............................................12
35 640788001 RIGHT FRONT COVER .............................................1
36 TBA DATA LABEL .............................................................1
37 511768001 HOUSING COVER.....................................................1
38 940140031 LABEL SENSORMATIC TAG .....................................1
39 280010091 PCB ASSEMBLY .......................................................1
40 270017006 SWITCH ASSEMBLY.................................................1
41 760342001 SWITCH ....................................................................1
42 730377003 POWER CORD..........................................................1
43 590274004 STRAIN RELIEF.........................................................1
44 220016096 GEAR BOX ASSEMBLY ............................................1
45 680911001 NEEDLE BEARING....................................................2
46 610388001 OUTPUT GEAR .........................................................1
47 300019002 BUSHING ASSEMBLY W/BEARING .........................1
48 680901001 NEEDLE BEARING....................................................1
