Safety
3
FEATURES
KNOW YOUR PRODUCT
See Figure 1.
The safe use of this product requires an understanding
of the information on the product and in this operator’s
manual, as well as a knowledge of the project you are
attempting. Before using the product, familiarize yourself
with all operating features and safety rules.
ADJUSTABLE FRONT HANDLE
The front handle assembly can be adjusted for ease of
operation and to help prevent loss of control.
EDGER GUIDE
The edger guide allows the line trimmer to perform as an
edger.
GRASS DEFLECTOR
The trimmer includes a grass deector that helps protect
from ying debris.
GRIPZONE™ OVERMOLD
GripZone™ overmold provides added user comfort.
LOCK-OUT BUTTON
The lock-out button prevents accidental starting.
ROTATING REAR HANDLE
The rotating rear handle can be locked in two different
positions for ease of use when edging and trimming.
TELESCOPING BOOM
The line trimmer can be adjusted to different extension
points for ease of use.
THREE-POSITION PIVOTING HEAD
The trimmer head can be adjusted with the pivot button.
ASSEMBLY
UNPACKING
This product requires assembly.
■ Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing
list are included.
WARNING
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage or
damage occurred during shipping.
■ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
■ If any parts are damaged or missing, please call Ryobi
Customer Service for assistance:
AUS: 1300 361 505
NZ: 0800 279 624
PACKING LIST
Line Trimmer
Grass Deector Assembly with Screws
Front Handle Assembly
Operator’s Manual
Battery (for RLT1830LiX4, RLT1830LiX5, RLT1830Li15,
and RLT1830Li13 only)
Charger (for RLT1830LiX4, RLT1830LiX5, RLT1830Li15,
and RLT1830Li13 only)
WARNING
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
WARNING
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
product when assembling parts.
DESCRIPTION
Figure 1
1. Switch trigger
2. GripZone™ overmold
3. Lock-out button
4. Adjustable front handle
5. Rear handle
6. Telescoping boom
7. 3-Position pivoting head
8. Edger guide
9. Grass deector
Figure 2
9. Grass deector
10. Head spool cover
11. Line cut-off blade
Figure 3
12. Screw holes
