OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
4 V COMPACT POWER SCRUBBER
BROSSEUSE ÉLECTRIQUE COMPACTE DE 4 V
LIMPIADOR ELÉCTRICO COMPACTO DE 4 V
P4400
GENERAL POWER TOOL SAFETY WARNINGS
GENERAL POWER TOOL SAFETY WARNINGS POWER SCRUBBER SAFETY WARNINGS
OPERATION
OPERATION
SYMBOLS
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s
Manual
To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Eye Protection
Always wear eye protection with side shields marked to comply with
ANSI Z87.1.
Recycle Symbol
This product uses lithium-ion (Li-ion) batteries. Local, state or federal
laws may prohibit disposal of batteries in ordinary trash. Consult your
local waste authority for information regarding available recycling
and/or disposal options.
Some of the following symbols may be used on this product. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
min Minutes Time
Direct Current Type or a characteristic of current
n
o
No Load Speed Rotational speed, at no load
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER:
Indicates a hazardous situation, which, if not avoided, will result in death
or serious injury.
WARNING:
Indicates a hazardous situation, which, if not avoided, could result in
death or serious injury.
CAUTION:
Indicates a hazardous situation, that, if not avoided, may result in minor
or moderate injury.
NOTICE:
(Without Safety Alert Symbol) Indicates information considered im-
portant, but not related to a potential injury (e.g. messages relating to
property damage).
ASSEMBLY
FEATURES
If any parts are damaged or missing, please call 1-800-525-2579 for assistance.
MAINTENANCE
WARNING:
When servicing, use only identical replacement
parts. Use of any other part could create a hazard
or cause product damage.
WARNING:
Always wear eye protection with side shields marked
to comply with ANSI Z87.1. Failure to do so could
result in objects being thrown into your eyes and
other possible serious injuries.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and can be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which could
result in serious personal injury.
REPLACING THE BRUSH ACCESSORY
See Figure 2.
After extended use, the brush accessory may wear
and need replacing. If you drop the tool and damage
the brush accessory it may also be necessary for you
to replace it. Refer to Installing/Removing Brush
Accessories earlier in this manual.
BATTERIES
This product is equipped with a lithium-ion rechargeable
battery. Length of service from each charging will
depend on the type of work you are doing.
The battery in this product has been designed to
provide maximum trouble-free life. However, like all
batteries, it will eventually wear out.
To obtain the longest possible battery life, we
suggest the following:
Remove the product from the charger once it is fully
charged and ready for use.
For product storage longer than 30 days:
Store the product where the temperature is below
80°F.
Store the product in a “discharged” condition.
BATTERY PACK REMOVAL AND
PREPARATION FOR RECYCLING
See Figures 4 - 5
Drain the battery by running the scrubber until it
shuts off.
Remove the screws, washer, USB cover, and end
cap from the tool.
Pull the battery carrier and circuit board assembly
out of the tool.
Release the tabs and separate the battery cover
from the circuit board.
Use wire cutters to cut the weld straps securing the
battery to the circuit board.
Remove the battery and apply tape over the ends
for disposal.
To preserve natural resources, please recycle or
dispose of batteries properly.
This product contains lithium-ion
batteries. Local, state or federal laws
may prohibit disposal of batteries in
ordinary trash.
Consult your local waste authority for
information regarding available recycling
and/or disposal options.
WARNING:
Upon removal, cover the battery pack’s terminals
with heavy-duty adhesive tape. Do not attempt to
destroy or disassemble battery pack or remove any
of its components. Lithium-ion batteries must be
recycled or disposed of properly. Also, never touch
both terminals with metal objects and/or body parts
as short circuit may result. Keep away from children.
Failure to comply with these warnings could result
in fire and/or serious injury.
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energizing power tools that have the switch
on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long
hair can be caught in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
Do not wear loose clothing or jewelry. Contain
long hair. Loose clothes, jewelry, or long hair can be
drawn into air vents.
Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of
the power tool in unexpected situations.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
Know your power tool. Read operator’s manual
carefully. Learn its applications and limitations, as
well as the specific potential hazards related to this
power tool. Following this rule will reduce the risk of
electric shock, fire, or serious injury.
Always wear eye protection with side shields marked
to comply with ANSI Z87.1 when assembling parts,
operating the tool, or performing maintenance.
Following this rule will reduce the risk of serious
personal injury.
This product is suitable for indoor and outdoor use.
Do not use battery-operated appliance in rain.
Check to make sure the brush accessory is installed
correctly prior to use.
Do not force the scrubber into tight spaces during
use.
Do not touch rotating accessories when product is
in use.
Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
when not using your battery tool or when changing
accessories. Following this rule will reduce the risk of
electric shock, fire, or serious personal injury.
WARNING:
Do not allow familiarity with this product to make
you careless. Remember that a careless fraction of
a second is sufficient to inflict serious injury.
WARNING:
Do not use this product if it is not completely
assembled or if any parts appear to be missing or
damaged. Use of a product that is not properly and
completely assembled or with damaged or missing
parts could result in serious personal injury.
Always close the battery cover and lock the tab
before use. Do not expose the battery pack to rain
or wet conditions. Water entering a power tool will
increase the risk of electric shock and fire.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of a GFCI reduces
the risk of electric shock.
Use only UL listed USB sources to charge this
device. Use of any non-UL Listed USB sources
may create a risk of fire.
PERSONAL SAFETY
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
Keep handles and grasping surfaces clean and
free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal
to another. Shorting the battery terminals together
may cause burns or a fire.
Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
or burns.
Do not use a battery pack or tool that is damaged
or modified. Damaged or modified batteries may
exhibit unpredictable behavior resulting in fire,
explosion, or risk of injury.
Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 265° F may cause explosion.
Do not charge battery tool in a damp or wet
location. Do not use, store, or charge battery
packs or products in locations where the
temperature is less than 50°F or more than 100°F.
Do not store outside or in vehicles.
SERVICE
Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
Do not place battery tools or their batteries near
fire or heat. This will reduce the risk of explosion and
possibly injury.
Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped
or received a sharp blow. A damaged battery is
subject to explosion. Properly dispose of a dropped
or damaged battery immediately.
Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush with
water immediately.
Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in
contact with your skin, wash immediately with soap
and water. If liquid gets into your eyes, flush them
with clean water for at least 10 minutes, then seek
immediate medical attention. Following this rule will
reduce the risk of serious personal injury.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If you
loan someone this tool, loan them these instructions
also.
WARNING:
Always wear eye protection with side shields marked
to comply with ANSI Z87.1. Failure to do so could
result in objects being thrown into your eyes and
other possible serious injuries.
WARNING:
Do not attempt to modify this product or create
accessories or attachments not recommended
for use with this product. Any such alteration
or modification is misuse and could result in a
hazardous condition leading to possible serious
personal injury.
WARNING:
Do not use any attachments or accessories not
recommended by the manufacturer of this product.
The use of attachments or accessories not
recommended can result in serious personal injury.
APPLICATIONS
You may use this product for the purposes listed below:
The power scrubber can be used to clean exterior
and interior surfaces.
This product is not for commercial use.
TO CHARGE
See Figure 1.
Turn the power scrubber off.
Remove the USB cover and insert the USB cable
into the product as shown.
Connect the USB cable to any powered USB port,
or connect it to a USB power adapter (not included)
and plug the adapter into a power supply.
NOTE: Make sure the power supply is normal
household voltage, 120 volts, AC only, 60 Hz.
The LED light will turn on while charging and turn off
once the power scrubber is fully charged or when
the USB cable is disconnected.
NOTE: If the LED does not turn on, the on/off button
may still be in the on position. Fully depress the on/
off button to stop the tool and begin charging.
Upon full battery depletion, an estimate of 5 hours
of charging time is required to fully recharge the
scrubber.
Do not place charger in an area of extreme heat or
cold. It will work best at normal room temperature.
Remove the product from the USB power adapter
(not included) or powered USB port once it is fully
charged and ready for use.
Disconnect the USB cable from the scrubber and
reinstall the USB cover.
SELECTING A BRUSH ACCESSORY
Selecting the correct type of brush accessory is
important in order to obtain the best performance from
the power scrubber. Select the brush accessory based
on the application and on the surface you wish to clean.
Selecting the right brush accessory will help you clean
more efficiently and protect the surface being cleaned.
To reduce the risk of property damage, always test
the brush in an inconspicuous area of a surface before
beginning a project.
NOTE: A brush accessory with medium bristles is
included with your power scrubber. Brush accessories
with hard and soft bristles can be purchased where you
bought this product.
BRUSH ACCESSORY SELECTION GUIDE
Soft Bristle (Blue)
Light Duty Cleaning
Medium Bristle (Green)
General Purpose Cleaning
Hard Bristle (Gray)
Heavy Duty Cleaning
INSTALLING/REMOVING BRUSH
ACCESSORIES
See Figure 2.
Insert the accessory into the collet and push it in as far
as possible. To remove an accessory, pull it straight
out of the collet.
STARTING/STOPPING THE POWER
SCRUBBER
See Figure 3.
To start the motor:
Fully depress the on/off button to start the motor.
NOTE: When the motor is on, the brush accessory
will spin continuously.
To stop the motor:
Fully depress the on/off button to stop the motor.
NOTE: When the motor is off, the brush accessory
will stop spinning.
OPERATING THE POWER SCRUBBER
See Figure 3.
Select the appropriate brush accessory.
Hold the scrubber firmly against the surface.
Fully depress the on/off button to start the power
scrubber.
Move the unit forward and back over the surface to
be cleaned.
NOTE: Move slowly when learning to use the unit
and when scrubbing tough or difficult stains.
NOTE: Do not press down on the unit or keep the
unit in one place over an extended period of time.
Doing so could damage the surface being cleaned.
When scrubbing is complete, fully depress the on/off
button to turn the motor off, and wait for the brush
accessory to stop spinning.
Remove the brush accessory as described earlier
and clean thoroughly.
NOTICE:
Dirt and debris can damage delicate surfaces.
Thoroughly rinse the brush accessory before use
and continue to do so at regular intervals during
use. Thoroughly clean the brush accessory after
use. Allow to dry and always store brush accessory
without bending the bristles.
P4400 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5
A - USB cable (câble USB, cable USB)
B - On/Off button (bouton marche/arrêt, botón de encendido/apagado)
C - Brush attachment (accessoire de brosse, aditamento de cepillo)
D - Handle (poignée, mango)
A- USB power adapter (not included) [adaptateur secteur USB (non inclus), adaptador de
alimentación USB (no incluido)]
B - USB cable (câble USB, cable USB)
C - USB port (port USB, puerto USB)
D - USB cover (convercle du USB, tapa del USB)
E - LED (DÉL, diodo luminiscente)
F - Powered USB port (port alimenté USB, puerto de alimentación USB)
A - Screws (vis, tornillos)
B - End cap (capuchon d’extrémité, tapa extremo)
C - Battery carrier (porte-piles, soporte para batería)
D - USB cover (convercle du USB, tapa del USB)
E - Tabs (languettes, orejetas)
F - Circuit board (carte de circuit imprimé, placa de circuitos)
G - Washer (rondelle, arandela)
A - Battery carrier (porte-piles, soporte para batería)
B - Battery (pile, batería)
C - Weld straps (bandes de soudure, tiras de soldadura)
D - Wire cutters (coupe-fil, cortador de alambre)
E - Circuit board (carte de circuit imprimé, placa de circuitos)
A - Brush attachment (accessoire de brosse, aditamento de cepillo)
B - Collet (collet, portaherramientas) A - On/Off button (bouton marche/arrêt, botón de encendido/apagado)
RYOBI is a trademark of Ryobi Limited and is used pursuant to a license granted by Ryobi Limited.
To request service, purchase replacement parts,
locate an Authorized Service Center and obtain Customer or Technical Support:
Visit www.ryobitools.com or call 1-800-525-2579
If any parts or accessories are damaged or missing,
do not return this product to the store. Call 1-800-525-2579 for immediate service.
Please obtain your model and serial number from the product data plate.
This product is covered under a 3-year limited Warranty. Proof of purchase is required.
*Model number on product may have additional letters at the end. These letters designate man-
ufacturing information and should be provided when calling for service.
MODEL NUMBER _______________ SERIAL NUMBER ____________________________
ONE WORLD TECHNOLOGIES, INC.
P.O. Box 1288, Anderson, SC 29622
1-800-525-2579 • www.ryobitools.com
FOR INDOOR AND OUTDOOR USE
POUR UTILISATION À L’EXTÉRIEUR ET L’INTÉRIEUR
PARA USARSE EN EL INTERIOR Y EXTERIOR
PRODUCT SPECIFICATIONS
Motor .......................................................................................................................................................... 4 V DC
No Load Speed (revolutions per minute) ..........................................................................approx. 175/min (RPM)
Charger Input.......................................................................................................................120 V, AC only, 60 Hz
Waterproof Rating .........................................................................................................................................IPX7*
* IP Rating: Specifies the environmental protection the product enclosure provides. This product has an IPX7 rating meaning
it can withstand immersion in water up to 1 meter for up to 30 minutes.
KNOW YOUR POWER SCRUBBER
The safe use of this product requires an understanding
of the information on the tool and in this operator’s
manual as well as a knowledge of the project you
are attempting. Before use of this product, familiarize
yourself with all operating features and safety rules.
HANDLE WITH OVERMOLD
The handle with overmold provides added user comfort.
USB CHARGING
This product features USB Charging functionality.
Utilize any powered USB port or USB power adapter
(not included) for effortless charging.
A
To Next Page
Loading...
