1. Carry handle
2. Air reducer valve
3. LCD display
4. Power indicator
5. Thermal cut out indicator / alarm
6. Current control knob
7. Earth clamp connection point (+ positive)
8. Gas hose
9. Cutting torch
10. Earth clamp
11. Cooling fan
12. Power lead
13. On/Off switch
14. Pressure gauge
15. Rocket switch
16. Gas/electric connection point
17. Interface for torch trigger
18. Fastening clips x 4
DESCRIPTION
13
