9
Fig. 6
BENT END OF
MUFFLER GUARD
OPENING IN REAR
HOUSING
MUFFLER GUARD ASSEMBLY
See Figure 6.
1. Remove muffler guard and two screws from the owner's
kit.
2. Attach the muffler guard to the rear housing.
NOTE: Make sure the bent end of the muffler guard fits
securely into the opening of the rear housing.
3. Using the torx wrench supplied, install the two screws
and tighten securely.
ASSEMBLY
SCREWS
MUFFLER
GUARD
REAR HOUSING
TORX
WRENCH
