Ryobi RA-C2550 - Product View

DESCRIPTION
Fig. 1
1
9
10
8
7
7
6
4
3
2
5
1. Air lter assembly
2. On/off switch
3. Tank pressure gauge
4. Pressure relief valve
5. Front handle
6. Pressure regulator knob
7. Quick connect coupler
8. Check valve
9. Regulated pressure gauge
10. Wheel
11. Rubber foot
12. Drain valve
13. Rear handle
14. Handle slot
15. Bolt
16. Flat washer
17. Hex nut
18. Wheel axle cover
19. Axle bolt
20. Oil ll hole cap
21. Sight glass
22. Red dot
23. Quick connect air tting
24. To close
25. Quick coupler
26. To open
27. Reset button
28. Drain valve knob
29. Ring
30. Air lter housing
31. Air lter
32. Air lter cover
33. Wing nut
34. Drain plug
