WARNING
If any parts are damaged or missing do not operate
this tool until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
WARNING
Do not attempt to modify this tool or create
accessories not recommended for use with this
tool. Any such alteration or modifi cation is misuse
and could result in a hazardous condition leading to
possible serious personal injury.
NOTE: The chain saw has been fully factory tested. It is
normal to fi nd some slight oil residue on the saw. Read
and remove all hang tags and store with the Operator·s
Manual.
See Figure 34-43.
Read the replacing the guide bar and chain section later
in this manual.
SPECIFICATIONS
DESCRIPTION (Fig. 1)
1. Front hand guard / Chain Brake
2. Front handle
3. Cylinder cover
4. Primer bulb
5. Choke knob
6. Clutch cover
7. Bar mounting nuts
8. Guide bar
9. Low kickback saw chain
10. Starter / fan housing
11. Starter grip
12. Ignition switch
13. Trigger release
14. Rear handle
15. Throttle trigger
16. Chain oil cap
17. Fuel cap
18. Spiked bumper
ASSEMBLY
RCS-3535C2 RCS-4040C2 RCS-4446C2
35 cc 40 cc 44 cc
Weight - No bar, chain, fuel or oil 4.6 kg 4.6 kg 4.6 kg
Fuel tank capacity 310 cm
3
310 cm
3
310 cm
3
Oil tank capacity 210 cm
3
210 cm
3
210 cm
3
Bar lengths 35 cm 40 cm 46 cm
Usable cutting lengths 320 mm 370 mm 410 mm
Bar type
Carlton 14-10-N1-MHC UNB Carlton 16-10-N1-MHC UNB Carlton 18-10W-K1-HC-UNB
Chain pitch 9.53 mm (0.375 inch) 9.53 mm (0.375 inch) 8.26 mm (0.325 inch)
Chain gauge 1.27 mm (0.05 inch) 1.27 mm (0.05 inch) 1.27 mm (0.05 inch)
Chain type
Carlton N1C-BL-M-52E SK Carlton N1C-BL-M-57E SK Carlton K1L-BL-72E
Drive sprocket 6-tooth 6-tooth 7-tooth
Engine displacement 35 cm
3
40.1 cm
3
44 cm
3
Maximum engine power (ISO7293) 1.7 kW / 10000 min-1 1.8 kW / 10000 min-1 1.9 kW / 9500 min-1
Maximum engine speed with attachment
12000 min-1 12000 min-1 12000 min-1
Idling engine speed 2700 - 3100 min-1 2700 - 3100 min-1 2700 - 3100 min-1
Specifi c fuel consumption at maximum
engine power
435g/kwh 435g/kwh 435g/kwh
Sound pressure level(ISO22868) 103 dB(A) 103 dB(A) 103 dB(A)
Sound power level (ISO22868) 113 dB(A) 113 dB(A) 113 dB(A)
Vibration (ISO22867)
- Front Handle 6.4 m/s
2
6.4 m/s
2
6.4 m/s
2
- Rear Handle 7.0 m/s
2
7.0 m/s
2
7.0 m/s
2
