Page 7
Fig. 1
FEATURES
LOCK-OFF
BUTTON
SWITCH
TRIGGER
BATTERY
PACK
SAW
BLADE
BLADE WRENCH
(5 mm HEX KEY)
BASE
(SHOE)
ASSEMBLY
LOCK-OFF
BUTTON
BLADE
WRENCH HOLDER
DEPRESS HERE TO
PULL SWITCH TRIGGER
