Ryobi RLM4619SME User Manual

6
English
SPECIFICATIONS
Engine 190cc OHV
No-load speed 2,700/min. (RPM)
Cutting path 460 mm
Height adjustments 10 positions, 10 mm−75 mm
Wheel size 7” front, 8” rear
Grass bag capacity 50 litres
Sound power level LwA 98.7 dB, K=3
Sound pressure level LpA 86.6 dB, K=3
Vibration: Left handle 9.721 m/s
2
, K=1.5
Vibration: Right handle 6.744 m/s
2
, K=1.5
Guaranteed value 98 dB
Net weight 35.25 kg
Gross weight 39.4 kg
Oil capacity 0.6 L
DESCRIPTION
See gure 1.
1. Primer bulb
2. Oil cap/dipstick
3. Fuel cap
4. Starter grip
5. Handle knob
6. Air lter element
7. Throttle
8. Grass catcher
9. Height adjustment lever
10. Rear discharge door
11. Spark plug boot
12. Rope guide knob
13. Mulching plug
ASSEMBLY
WARNING
If any parts are damaged or missing do not operate this
product until the parts are replaced. Operation of this
product with damaged or missing parts could result in
serious personal injury.
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modication is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
WARNING
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark
plug wire from the spark plug when assembling parts.
WARNING
Never attach or adjust any accessory while the mower
is running. Failure to stop the engine may cause serious
personal injury.
WARNING
Never operate the mower without properly working
safety devices in place and working. Never operate
the mower with damaged safety devices. Operation of
the mower without properly working safety devices can
result in serious personal injury.
See gure 2 - 5.
■ Place handles in correct operating position and tighten
handle knobs to secure.
■ Install grass catcher or mulching plug.
INSTALLING THE MULCHING PLUG (FOR MULCHING
OPERATION)
See gure 3.
NOTE: When using the mulching plug, do not install the
grass catcher.
■ Lift and hold up the rear discharge door.
■ Grasp the mulching plug by its handle and insert it at a
slight angle, as shown.
■ Push the mulching plug securely into place.
■ Lower the rear discharge door.
REMOVING THE MULCHING PLUG
NOTE: When using the mulching plug, remove the grass
catcher.
■ Lift and hold up the rear discharge door.
■ Grasp the mulching plug by its handle and remove it
from the product.
ASSEMBLING THE GRASS CATCHER
See gure 4.
■ Snap the filter in place on the inner side of the top
cover.
