RYOBI POWER HEAD – ITEM NO. RY40006/RY40006VNM
3
KEY PART
NO. NUMBER DESCRIPTION QTY
1 314829002 Boom Assembly (Inc. Key Nos. 2-4 and 16, RY40006) ....................................................................................................... 1
315832001 Boom Assembly (Inc. Key Nos. 2-4 and 16, RY40006VNM) ............................................................................................... 1
2 941013004 Warning Icon Label .............................................................................................................................................................. 1
3 941013005 Warning Label (French/Spanish) .......................................................................................................................................... 1
4 941588367 Data Label (RY40006) .......................................................................................................................................................... 1
941588476 Data Label (RY40006VNM) .................................................................................................................................................. 1
5 314562001 Boom Clamp Assembly ....................................................................................................................................................... 1
6 314832002 Motor, Gear Box, Switch & Contact Plate Assembly ........................................................................................................... 1
7 570115001 Rubber Plate ........................................................................................................................................................................ 2
8 308056009 Front Handle Assembly (Inc. Key Nos. 9-10 & 15) ............................................................................................................... 1
9 660857001 Screw (1/4-20 x 40 mm, Hex Hd.)........................................................................................................................................ 1
10 518949001 Wing Nut (1/4-20) ................................................................................................................................................................. 1
11 314830001 Rear Handle Assembly (Inc. Key No. 12) ............................................................................................................................. 1
12 940705432 Logo Label ........................................................................................................................................................................... 2
13 661864007 Screw (M4 x 18 mm, T15 Torx Pan Hd.) ............................................................................................................................ 11
14 314833001 Switch Trigger Assembly ...................................................................................................................................................... 1
15 639167001 Assist Handle Clamp ............................................................................................................................................................ 1
16 941851150 Attachment Label ................................................................................................................................................................. 1
17 660031017 Screw (M3.5 x 16 mm, T10 Torx Pan Hd.) ........................................................................................................................... 1
Not Shown
995000659 Operator’s Manual
11-21-19
(Rev:02)
The item and manufacturing number will be found on a label attached to the boom assembly. Always mention the item and manufacturing
number of your POWER HEAD when requesting service or ordering repair parts.
PARTS LIST
