Page 12 – English
The model number will be found on a plate attached to the engine housing. Always mention the model number
in all correspondence regarding your HEDGE TRIMMER or when ordering replacement parts.
PARTS LIST
1 34107458G Debris Deflector .........................................................................................................1
2 34201162G Deflector Retainer ......................................................................................................1
3 33211442G Blade Cover ...............................................................................................................1
988000432 Operator’s Manual
KEY PART
NO. NUMBER DESCRIPTION QTY
ILLUSTRATED PARTS LIST
1
2
3
