3
RYOBI TP26 GAS PRUNER
MODEL NO. RY52604/RY52907
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
GAS PRUNER or when ordering replacement parts.
FIGURE A PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
18 638565001 Handle Bar Clamp Bottom “J” ....................1
19 678013001 Washer .........................................................1
20 518949001 Wing Nut (1/4-20) ........................................1
21 678012001 Lock Washer ................................................1
22 518696001 Throttle Trigger ............................................1
23 308224001 Strap Hanger Assembly ...............................1
24 308842004 Throttle and Lead Assembly
(Incl. Key No. 5) ...........................................1
25 308487001 Shoulder Harness ........................................1
26 678029002 Hex Nut (M6) ................................................1
27 690694002 Spring ..........................................................1
28 660881001 Combination Wrench ...................................1
29 690140011 Compression Spring ....................................1
Not Shown:
987000428 Operator’s Manual .......................................1
940705011 Logo Label ...................................................1
940991029 Model Label (TP26) ......................................1
1 660563002 Screw (M4 x 20 mm) ....................................4
2 308869002 Control Handle Assembly ............................1
3 518695001 Trigger Lock .................................................1
4 638431001 Strap Hanger ...............................................1
5 760700002 Switch (Momentary Contact) .......................1
6 570234002 Rear Handle .................................................1
7 870174001 Spark Plug (Champion RCJ6Y) ...................1
8 660634001 Screw (8-16 x 5/16 in., Torx T.F.) ..................1
9 518777001 Air Filter Cover .............................................1
10 308680001 Fuel Cap Assembly (1.5 in. Diameter) .........1
300758006 Fuel Cap Assembly (2 in. Diameter) ............1
11 940686026 Starting Label ..............................................1
12 660697002 Bolt (M6 x 20 mm) .......................................1
13 308470004 Upper Boom Assembly ...............................1
14 940657034 Warning Decal .............................................1
15 638564001 Handle Bar Clamp Top “J” ..........................1
16 660643001 Bolt (1/4-20 x 1-1/2 in., Hex Hd.) ................1
17 308046001 “J” Handle w/Grip ........................................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
