RYOBI TP26 GAS PRUNER
MODEL NO. RY52604/RY52907
PARTS LIST (FIGURE B)
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
GAS PRUNER or when ordering replacement parts.
1 308680010 Oil Cap Assembly .................................................... 1
2 660934003 Screw (M5 x 18 mm) ................................................ 4
3 580877001 Oil Tank Cover Assembly ......................................... 1
4 308513001 Oil Pickup Assembly ................................................ 1
5 660913001 Screw (M5 x 25 mm) ................................................ 3
6 660910002 Screw (M8 x 35 mm) ................................................ 1
7 308532002 Gear Case Assembly ............................................... 1
8 660617001 Worm Gear ............................................................... 1
9 308523001 Oil Pump Seal Assembly ......................................... 1
10 660912001 Screw (M5 x 13 mm) ................................................ 2
11 638282001 Bar Pad Plate ...........................................................1
12 671834008 Guide Bar .................................................................1
13 678355001 Hex Nut (M8) ............................................................1
14 120530009 Bar Clamp Assembly ............................................... 1
15 690583003 Chain (10 in.) ............................................................ 1
16 678354001 E-ring (Ø6 mm) ........................................................ 1
17 631060001 Cupped Washer ....................................................... 1
18 610618001 Sprocket .................................................................. 1
19 308520001 Oil Pump Housing w/Cam Pin Assembly ................ 1
20 308524001 Pinion Gear & Plunger Assembly ............................. 1
21 308519001 Output Shaft Assembly ............................................ 1
22 308514001 Pinion and Bearing Assembly .................................. 1
23 678284001 Lock Washer (5 mm) ................................................ 1
24 660911001 Screw (M5 x 15 mm) ................................................ 1
25 660935001 Screw (M5 x 25 mm) ................................................ 1
26 518019002 Hanger Cap ............................................................. 1
27 308010006 Intermediate Boom Assembly ................................. 1
28 940726013 Logo Label ............................................................... 1
29 940657030 Warning Label .......................................................... 1
30 120530008 Lower Drive Shaft Assembly
(Incl. Key No. 28-29) ................................................ 1
31 308400005 Gear Head Assembly
(Incl. Key Nos. 1-11, 13-14 and 16-25) ................... 1
32 518405001 Scabbard ................................................................. 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
