iii
A - Push pins in and pull up on handle to remove
(push pins in and pull up on handle to remove,
pins in and pull up on handle to remove)
B - Push to insert (pousser pour insert, presione
para insertar)
Fig. 4
Fig. 5
A - Trigger handle (poignée à gâchette,
mango del gatillo)
B - Connector (connecteur, conector)
C - Spray wand (lance de pulvérisation,
tubo de rociado)
D - Auxiliary handle (auxiliary handle, auxiliary
handle)
A - Collar (collier, casquillo)
B - Inlet coupler (raccord d’entrée, acoplador de
entrada)
C - High pressure hose (tuyau haute pression,
manguera de alta presión)
A
B
A
B
A
B
A
B
C
C
D
Fig. 6
A - Threaded outlet (raccord fileté, salida con
rosca)
B - Collar (collier, casquillo)
B
A
Fig. 7
A - Water intake (rise d’eau, entrada de agua)
B - Screen (tamis, cedazo)
C - Garden hose (tuyau d’arrosage, manguera de
jardín)
A
C
B
Fig. 3
Fig. 8
A - Oil cap/dipstick (bouchon / jauge d’huile, tapa
del aceite con varilla de nivel)
A
