5
DIGITAL INVERTER GENERATOR – ITEM NUMBER RYi2200GR/RYi2200GRA
The model number will be found on a label attached to the back cover. Always mention the model number in all correspondence regarding your
DIGITAL INVERTER GENERATOR or when ordering parts.
PARTS LIST – FIGURE B
KEY PART
NO. NUMBER DESCRIPTION QTY
1 518728010 Front Cover ................................................................................................................................................................... 1
2 638701035 Handle Tube .................................................................................................................................................................. 2
3 525361013 Handle Cap (Left) .......................................................................................................................................................... 2
4 525361012 Handle Cap (Right) ........................................................................................................................................................ 2
5 525529003 Bottom Base ................................................................................................................................................................. 1
6 519813034 Oil Drain Door................................................................................................................................................................ 1
7 308790086 Handle Assembly .......................................................................................................................................................... 1
8 524012015 Back Cover ................................................................................................................................................................... 1
9 561454006 Isolator Foot .................................................................................................................................................................. 2
10 570712008 Engine Support Isolator (Back) ..................................................................................................................................... 1
11 570712007 Engine Support Isolator (Front) ..................................................................................................................................... 1
12 570712009 Handle Bumper ............................................................................................................................................................. 1
13 660342013 Screw (M5 x 12 mm, Pan Hd.) ...................................................................................................................................... 2
14 678900014 U-Clip (M5) .................................................................................................................................................................... 6
15 660764010 Screw (M5 x 20 mm, Button Soc. Hd.) ......................................................................................................................... 4
16 638128014 Washer (M5.3) ............................................................................................................................................................... 6
17 660975004 Bolt (M6 x 12 mm, Hex Hd.) .......................................................................................................................................... 4
18 678012001 Lock Washer ................................................................................................................................................................. 4
19 660764012 Screw (M5 x 16 mm, Flat Hd.) ...................................................................................................................................... 4
