DIGITAL INVERTER GENERATOR – ITEM NUMBER RYi2200GR/RYi2200GRA
PARTS LIST – FIGURE D
The model number will be found on a label attached to the back cover. Always mention the model number in all correspondence regarding your
DIGITAL INVERTER GENERATOR or when ordering parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
1 638700043 Front Cover .........................................................................................................................................................................1
2 760945005 Reset Button ....................................................................................................................................................................... 1
3 760504016 Auto Idle Switch ..................................................................................................................................................................1
4 870932002 Connector (Black) ...............................................................................................................................................................2
5 780350007 Circuit Breaker (20A) ...........................................................................................................................................................1
6 290400017 120 Volt Duplex Receptacle (20 Amp) ................................................................................................................................1
7 570412014 Receptacle Cover (Front) ....................................................................................................................................................1
8 570412015 Receptacle Cover ...............................................................................................................................................................1
9 570412012 Clip ......................................................................................................................................................................................1
10 679449001 Spring .................................................................................................................................................................................1
11 638623005 Flat Washer (OD10 x ID5.3 x 0.5t) ......................................................................................................................................3
12 678343003 Lock Washer (OD9 x ID5 x 1.3t) ..........................................................................................................................................1
13 678016008 Hex Nut (M5) ....................................................................................................................................................................... 1
14 660976002 Bolt (M5 x 16 mm, Pan Hd.) ...............................................................................................................................................1
15 660345025 Bolt (M4 x 10 mm, T15 Torx Hd.) ........................................................................................................................................ 2
16 690969002 Washer (OD10 x 4.2 x 1t) ....................................................................................................................................................2
17 661514002 Hex Nut (M4) ....................................................................................................................................................................... 2
18 290514015 Internal Wire Assembly .......................................................................................................................................................1
19 290404011 Ground Wire ........................................................................................................................................................................ 1
20 660901004 Screw (M6-20 x 0.38 mm, T15 Torx Pan HD.) ....................................................................................................................4
21 519707015 Electrical Panel Housing ..................................................................................................................................................... 1
22 678016009 Wing Nut (M5) .....................................................................................................................................................................1
23 270290022 Indicator (Red LED 3.3V-4mA) ............................................................................................................................................1
