Page 16
OPERATION
LEVEL DRILLING
See Figures 12 and 13.
A convenient new feature provided with your drill is a level.
It is recessed in the motor housing on top of your drill. It
can be used to keep drill bit level during drilling operations.
WARNING:
Do not force tool. Forcing tool can result in jamming
and loss of balance or footing, which could result in
personal injury.
MAG TRAY™
See Figure 14.
For convenience, your drill has a Mag Tray™ to place small
parts when doing a variety of tasks.
MAG TRAY™
(SCREW HOLDER)
Fig. 14
LEVEL
Fig. 13
TOP VIEW
20
24
