Page 23
The model number will be found on a plate attached to the base. Always mention the model number in all correspondence regarding your SCROLL
SAW or when ordering repair parts.
RYOBI 16 in. SCROLL SAW – MODEL NUMBER SC155VS
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
PARTS LIST FOR FIGURE B
Key Part
No. Number Description Quan.
Key Part
No. Number Description Quan.
1 102039004 Table Screw ............................................................ 1
2 105015009 Table........................................................................ 1
3 190030500 * Screw (M5 x 8 Pan Hd.) ..........................................3
4 979766001 Screw (M4 x 16 Pan Hd.) ........................................ 2
5 168041001 Warning Label ......................................................... 1
6 981365001 Cover Plate.............................................................. 1
7 981369001 Nozzle...................................................................... 1
8 300305015 * Hex Bolt (M5 x 16)................................................... 3
9 Incl w/#8 Washer (M5) ............................................................ 3
10 981362001 Base ........................................................................ 1
11 981363001 Data Plate................................................................ 1
12 979791001 Strain Relief ............................................................. 1
13 979790001 Cord Assembly ........................................................ 1
14 981377001 Motor Cover............................................................. 1
15 981378001 Screw (M5 x 12 Pan Hd.) ........................................ 5
16 981375001 Control Box Cover ...................................................1
17 981372001 PC Board Assembly ................................................ 1
18 979798001 Gasket ..................................................................... 1
19 981376001 Control Box.............................................................. 1
20 981373001 Switch Knob ............................................................ 1
21 981370001 Switch Label ............................................................ 1
22 981371001 Screw (M5 x 9 Pan Hd.) ..........................................3
23 981396001 Brush Assembly....................................................... 2
24 981374001 Screw (M4 x 15 Pan Hd.) ........................................2
25 981397001 Brush Cap ............................................................... 2
26 980123001 Motor Assembly ....................................................... 1
27 350308161 * Spring Washer (M8) ................................................ 2
28 360308000 * Lock Washer (M8) ................................................... 2
29 100308020 Screw (M8 x 25 Hex Hd.) ........................................2
30 981364001 Table Support .......................................................... 1
31 160030400 * Screw (M4 x 8 Pan Hd.) .......................................... 3
32 981379001 Star Washer (M5) .................................................... 1
33 100030501 * Screw (M5 x 15 Pan Hd.) ........................................ 4
34 360305000 * Lock Washer (M5) ................................................... 7
35 981367001 Spacer ..................................................................... 3
36 104022003 Pointer ..................................................................... 1
37 190030500 * Screw (M5 x 8 Pan Hd.) .......................................... 3
38 981361001 Support Screw ......................................................... 1
39 350306162 * Washer (M6)............................................................ 2
40 105018007 Bevel Scale ............................................................. 1
41 104056002 Lock Lever ............................................................... 1
42 101060002 "T" Handle Wrench .................................................. 1
43 101058102 Blade Changing Rod ............................................... 1
972000-704 Operator's Manual
* Standard Hardware Item – May Be Purchased Locally
