FEATURES
WRENCH (2)
MOTOR
HOUSING
ON
OFF
DEPTH OF
CUT SCALE
BRUSH CAP
BASE
COLLET NUT
COLLET
SUBBASE
ADJUSTMENTS
Fig. 2
WING BOLT
ON-OFF
SWITCH
WARNING:
Your laminate trimmer should never be connected to
power supply when you are assembling parts, making
adjustments, installing or removing cutters, or when not
in use. Disconnecting your trimmer will prevent accidental
starting that could cause serious injury.
WARNING:
Do not use cutters that are larger in diameter than the
opening in trimmer base. Use of such cutters will come
in contact with the trimmer base and damage both the
cutter and trimmer base. This situation could also cause
possible loss of control or create other hazardous
conditions that could cause possible serious personal
injury.
WARNING:
Do not use cutters with undersized shanks. Undersized
shanks will not tighten properly and could be thrown from
tool causing injury.
