LOOSE PARTS LIST
1. Seat assembly x 1
2. Drive handles x 2
3. Charger x 1
4. Hitch plate assembly
Hitch plate x 1
Bolts x 2
5. Tool kit
Open-ended spanners x 2
Torx wrench x 1
6. Keys x 3
1.
3.
6.
2.
4.
5.
WARNING
If any parts are damaged or missing do not
assemble the product until the parts are
replaced with new original manufacturer’s
parts. Assembling the product with
damaged, missing, or incorrect parts could
result in serious personal injury.
3 English |
