62 Car care and scheduled maintenance
common color. The rating is also marked 19
on the fuse.
If the same fuse blows repeatedly, take the 20
car to an authorized Saab dealer and have
the wiring and other electrical equipment 21
checked. 22
Fuse
No.
1-3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Fuse/
Function
Blank
Amperage
Shift indicator light 10
Windshield wipers/washers,
brake fluid warning light 15
ACsystem 30
Turn Signals, rev counter 15
Electrically
adjusted
rear-view mirrors,
cruise control 10
Ventilation fan 30
APC system 10
Power windows, sunroof 30
Seat heaters 15
Back up lights; seat belt
and charge warning
lights; cigarette lighter 20
High beam, RH 15
High
beam, LH; high
warning light 15
Low beam, RH 15
Low beam, LH 15
Parking lights, RH; tail
light, RH;number plate
illumination; glove
compartment, ashtray and
instrument illumination 10
23
24
25
26
27
28
29
30
31
Parking light, LH; tail
lightLH 10
Radio/cassette player,
cornering light 15
Fog lights 15
Relay trigger
(ind.fuel
pump, rear demist, cooling
fan time relays) 10
Blank
Central locking
Radiator cooling
fan
Horn
Hazard warning lights
Interior lighting, dock
radio memory and/or
amplifier(s), electric
antenna
Heated rear window
Fuel pumps
Brake lights
Oxygen sensor wire
10
30
25
15
15
20
20
15
5
Relays
The relay panel ahead of the left front whe-
~lhouse on cars with 8 valve engines conta-
InS the following relays:
Position Function Part number
A (Blank)
B-C Transient
enrichment
relay
8584732
0 Pre-wired for
fog light
relay
0280495
E
Decel
system relay
(manual trans.)
8599425
F
Hot start
pulse relay
8568271
G
(Blank)
H
(Blank)
~FRONT
SG485
