2. Connect it to the branch drain pipe of the trough.
It can drain the water up and
down, outlet hose shall not be
installed at a height beyond
100cm and its end shall not be
immersed in water.
Position outlet hose properly so that the oor will not be
damaged by water leakage.
Min.60cm
Max. 100cm
Max. 100cm
Min.60cm
Install inlet pipe
1. Connect the elbow to tap and fasten it
clockwise.
2. Connect the other end of inlet pipe
to the inlet valve at the backside of
washing machine and fasten the pipe
tightly clockwise.
Notes: after connection, if there is any leakage with hose, then
repeat the steps to connect inlet pipe. The most common type of
tap shall be used to supply water. If tap is square or too big, then
standard tap shall be changed.
Place outlet hose
There are two ways to place the end of
outlet hose:
1. Put it beside the water trough.
6362
