Turntable Installation
Turntable shaft
Turntable ring assembly
Hub (underside)
Glass tray
a� Never place the glass tray upside down� The glass tray should
never be restricted�
b� Both glass tray and turntable ring assembly must always be
used during cooking�
c� All food and containers of food are always placed on the
glass tray for cooking�
d� If glass tray or turntable ring assembly cracks or breaks, con-
tact your nearest authorized service center�
Countertop Installation
Remove all packing material and accessories� Examine the oven
for any damage such as dents or broken door� Do not install if
oven is damaged�
Cabinet: Remove any protective lm found on the microwave
oven cabinet surface�
Do not remove the light brown Mica cover that is attached to the
oven cavity to protect the magnetron�
Installation
1� Select a level surface that provides enough open space for
the intake and/or outlet vents�
1)� The minimum installation height is 85cm�
2)� The rear surface of appliance shall be placed against a wall�
Leave a minimum clearance of 30cm above the oven, a mini-
mum clearance of 20cm is required between the oven and
any adjacent walls�
3)� Do not remove the legs from the bottom of the oven�
4)� Blocking the intake and/ or outlet openings can damage the
oven�
5)� Place the oven as far away from radios and TV as possible�
Operation of microwave oven may cause interference to your
radio or TV reception�
