With engine stopped, check its oil level
which must be between the MIN and MAX
marks on the dipstick.
Refuel using a funnel, but do not complete-
ly fill the tank.
The tank's capacity is about 4 litres.
Refuelling should be carried out in an open or well venti-
lated area with engine stopped. Always remember that petrol fumes are
inflammable. DO NOT TAKE FLAMES TO THE TANK MOUTH TO VERIFY
ITS CONTENTS AND DO NOT SMOKE WHEN REFUELLING.
T
YRE PRESSURE
Having the correct tyre pressure is essen-
tial for keeping the cutting deck horizontal
and thus achieving uniform mowing.
Unscrew the valve protection cap and
connect the valves to a compressed air
line with a gauge.
Pressures are:
FRONT 1.5 bar
REAR 1.0 bar
!
DANGER!
ENG 18 HOW TO USE THE MACHINE
