11
20°
46°
72°
An alternative method would be to release the Hinge Lock, and
fully open the leg to 90°
Avoid trapping
90°
Move the leg towards the body. As the leg passes each lock point,
an audible click will be heard, the leg is prevented from opening
Engage the lock.
