11
0,01 0.12 0.12 0.23
0,1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation
distance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter,
where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
Rated maximum
output power of
transmitter
W 150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2,5 GHz
emc information
Recommended separation distances between portable and mobile RF communications
equipment and the SAD Solutions Bluelight
The “SAD Solutions Bluelight” is intended for use in an electromagnetic environment in which
radiated RF disturbances are controlled. The customer or the user of the SAD Solutions Bluelight can
help prevent electromagnetic interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the “SAD Solutions Bluelight” as
recommended below, according to the maximum output power of the communications equipment.
technical specifications
Model No. 1708 SAD Solutions BLUElight
Power Input 9v DC up to 1.1A via external Transformer / Adaptor
Batteries Rechargeable Li-Ion Polymer. Capacity 850MA
Battery Performance Fully charged LED Run time + 3hrs at full intensity
Blue LEDs 60 x single peak wavelength 470 - 475 nm
LED life Approx. 30,000 hrs
Light Output 350-400 LUX at full intensity
At 100% intensity energy between 1.5 – 2.5 mW/cmÇ @ 18”
Display ELP – Backlit LCD
Plastic Material PC and ABS Plastic
Separation distance according to frequency of transmitter m
