Saeco CAFE NOVA - Grinder Disassembly Process

DISASSEMBLY VIENNA
7. Disassembling the grinder
a) Remove the two fixing screws (1). Remove the fixing screw on the upper grind
adjustment ring (2).
Fig. 18
b) Release the three fastening tabs (1) on the underside and remove the upper grind
adjustment ring (2).
Fig. 19
1
2
1
2
