Saeco VIENNA PLUS - Disassembly and Adjustment Procedures; Disassembly of the Housing

VIENNA DISASSEMBLY
1. Disassembly of the housing
a) Remove the water tank and the coffee bean container cover.
b) Remove the two fixing screws (1) of the coffee bean container.
Fig.
1
c) Remove the housing screw (1) under the water tank (Torx/T10).
d) Remove the housing screw (2) under the coffee bean container.
Fig. 2
1
1
2
