SafeLine THOR v.2.5.0 EN / DE / SE

Bottomcard

Bottenkort

Untere Platine

X15

Relay/Relais/Relä

Output230VAC3.1-3.2

Ausgang230VAC3.1-3.2

Utgång230VAC3.1-3.2

1 C

Common for Pilot relays: K11 - K12

Gemeinsam für Vorsteuerrelais Relais: K11- K12

Gemensam körrelä: K11 - K12

2 O 3.2 K12

3 O 3.1 K11

X16

Relay/Relais/Relä

Output230VAC3.3-3.4

Ausgang230VAC3.3-3.4

Utgång230VAC3.3-3.4

1 O 3.4 K14

2 O 3.3 K13
