Saft 4579 - FITS AND CLEARANCES; Torque Table

SAFT AMERICA INC.
COMPONENT MAINTENANCE MANUAL
4579
24-31-05
PAGE 801/802 Blank
Jan 30/98
FITS AND CLEARANCES
1. Torque Table
Figure 801 is a listing of all pertinent torque values needed to assemble and service the
battery.
NOTE: The values listed in Fig 801 are “lube torque” values. The threads should be
lightly greased prior to installation and applying torque.
Figure / Item Number Torque Value Name, Location
IPL Fig 1
IPL Fig 1
IPL Fig 1
5
5
18
87 ±17.4 lbs.-in (10 ±2 N•m)
43.5 ± 17.4 lbs.-in (5 ±0.5 Nm)
20 lbs.-in (2.30Nm)
Nut, Terminal, Upper
Nut, Terminal, Lower
Screws, Receptacle
Torque Table
Fig 801
2. Fits and Clearances Table
No fits and clearances required.
