5. Router supervision
You can monitor the router’s activity and status using the following sources:
• status of the LEDs on the front panel of the router
• using the router’s built-in «DSL Router» HTTP controller, available in the HTTP configuration tool
Status of the LEDs on the front panel
LED Status Meaning
Power
Off Power Off
Green Power On
Red Router in rescue mode
ADSL
Off ADSL Down
Green steady ADSL Up
Green blinking ADSL Synchronisation in progress
Internet
Off
• Power Off
or
• The Internet account must be configured
Green steady
• The Internet account is configured
or
• Bridge mode
Green blinking Tx/Rx traffic
Red Invalid or unauthorised Internet account
LAN x
(1 to 4)
Off No link detected on the Ethernet port
Green steady Ethernet port has detected a link with 100 Mbps device
Green blinking Tx/Rx traffic at 100 Mbps
WLAN
Off Wi-Fi deactivated
Green steady WI-Fi activated
Green blinking Wi-Fi Tx/Rx
